Conductor: Annealed copper, Class 6 or finer stranding (tinned on request)
Insulation: HDPE-insulated cores
Core Filler: PE strips
Separator: Copper foil
Shield: Tinned copper braid, 85% coverage
Jacket: High-performance PVC compound
Oil Resistance: Meets EN 50363-4-1
Flame Retardancy: Meets IEC 60332-1-2
Color: Green
Outer Diameter: 7.2 ± 0.3 mm
Drag-Chain Life: 10 million cycles
